Printing method: Direct thermal & Thermal Transfer
Printing resolution: 300dpi
Printing Speed: 1~up to 4ips (25.4~101.6mm/s)
Printing Length: Max 50”(1270mm) / Min 0.2”(5mm)
Printing Width: Max 4.1”(104mm)
Memory: 8MB DRAM (5MB user available)
8MB Flash ROM (6MB user available)
CPU Type: 32 bit RISC microprocessor
Sensors: Media gap & black line Reflective sensor x 1 (Movable) & Transmissive sensor x 1(Center fixed) / Head open switch / Ribbon end sensor
Operation Interface: LED Indicator(Power/Ready)x2, Botton(Feed)x1
Communication Interface: Parellel, RS-232, USB, Ethernet
Fonts: Internal character sets standard 5 alpha-numeric fonts from 0.049”H ~ 0.23” H (1.25mm ~ 6.0mm)
Internal fonts are expandable up to 24x24
4 direction 0° ~ 270° rotation
Soft fonts are downloadable
1D Barcodes
PPLA: Code 39 (standard/with checksum digit), Code 93 Interleaved 2of 5 (standard/with checksum digit/with human readable check digit), EAN-8, EAN-13,UPC-A, UPC-E, Postnet, Codabar, Code 128 subset A/B/C, UCC/EAN-128, UCC/EAN-128 K-MART, UCC/EAN-128 , Random Weight, Plessey, HBIC, Telepen, FIM, UPC2, UPC5, GS1 Data Bar
|
·PPLB: Code 39 (standard/with checksum digit),Code 93 Interleaved 2 of 5 (standard/with checksum digit/with human readable check digit), EAN-8 (standard/2 digit add-on/5 digit add-on), EAN-13 (standard/2 digit add-on/5 digit add-on), UPC-A (standard/2 digit add-on/5digit add-on), UPC-E (standard/2 digit add-on/5 digit add-on), Postnet, Codabar, Code 128 subset A/B/C, Code 128 UCC (Shipping Container Code), Code 128 Auto, German, Postcode, Matrix 2 of 5, UCC/EAN 128, UPC Interleaved 2 of 5, GS1 Data Bar
2D Barcodes
PPLA/PPLB: MaxiCode, PDF417, Data Matrix (ECC200 only), QR code, Composite codes
Graphics: PPLA: PCX, BMP, IMG and HEX format files
PPLB: PCX and Binary raster, BMP and GDI
Emulation: PPLA, PPLB
Windows Driver
Media Type: Roll-feed, die cut, continuous, fan-fold, tags, ticket in thermal paper or plain paper and fabric label
Media: Max Width: 4.3”(110mm); Min Width:1”(25.4mm)
Thickness: 0.0025”~0.01”(0.0635~0.254mm)
Max roll capacity(OD): 5”(127mm)/Core size:1”(25.4mm)
optional:Max roll capacity(OD):4.5(114.3mm)/Core size:0.5(12.7mm)
Ribbon: Ribbon roll-max OD:2.6(67mm)
Ribbon Length: max 300m; Core size - ID:1”(25.4mm)
Ribbon Width: 1”~4” Wax, Wax/Resin, Resin (Ribbon wound ink-side out or ink-side in available)
Dimensions: L273mm x W225mm x H186mm
Weight: 2.1Kg
Power Source: Universal Switching Power Supply AC Input:100~240V,1.5A, 50-60Hz
DC Output: 24V, 2.91A Typical, 70W Max.
Optional Items: Cutter
Agency Listing: CE, FCC, cTUVus, CCC, RoHS
|
|
|
|
|
|
|
